| Nominal diameter | 10"/254mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 200 W |
| Power rating | 400 W |
| Sensitivity | 96dB |
| Frequency range | 52-4000 Hz |
| Maqnet Size | 170mm |
| Voice coil diametel | 65mm/2.5 inch |
| Coil material | PICCAW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 9.1mm |
| Fs | 52 HZ |
| Qts | 0.32 |
| VAS | 46.6 L |
| Bl | 13.6 Tm |
| Net Weight | 5 kg/pc |
