| Nominal diameter | 10"/261mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 350 W |
| Power rating | 700 W |
| Sensitivity | 97dB |
| Frequency range | 59-3000 Hz |
| Maqnet Size | 180mm |
| Voice coil diametel | 75mm/3 inch |
| Coil material | PICCAW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 6.6mm |
| Fs | 59 HZ |
| Qts | 0.36 |
| VAS | 30.9 L |
| Bl | 14.8 Tm |
| Net Weight | 5.8 kg/pc |
