| Nominal diameter | 12"/305mm |
| Magnet type | Neodymium |
| Impedance | 16Ω |
| AES Power | 400 W |
| Power rating | 800 W |
| Sensitivity | 98dB |
| Frequency range | 53-2500 Hz |
| Maqnet Size | 131mm |
| Voice coil diametel | 75mm/3 inch |
| Coil material | PIALW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 7.7mm |
| Fs | 53 HZ |
| Qts | 0.32 |
| VAS | 55 L |
| Bl | 24.2 Tm |
| Net Weight | 5.2 kg/pc |
