| Nominal diameter | 12"/310mm |
| Magnet type | Neodymium |
| Impedance | 8Ω |
| AES Power | 500 W |
| Power rating | 1000 W |
| Sensitivity | 96dB |
| Frequency range | 46-2500 Hz |
| Maqnet Size | 75mm |
| Voice coil diametel | 75mm/3 inch |
| Coil material | PIALR |
| Number of layers | 1L(Inside/Outside) |
| X-max | 7.5mm |
| Fs | 46 HZ |
| Qts | 0.28 |
| VAS | 56 L |
| Bl | 21.1 Tm |
| Net Weight | 3.8 kg/pc |
