| Nominal diameter | 12"/305mm |
| Magnet type | Ferrite |
| Impedance | 4Ω |
| AES Power | 300 W |
| Power rating | 600 W |
| Sensitivity | 96dB |
| Frequency range | 35-2500 Hz |
| Maqnet Size | 156mm |
| Voice coil diametel | 50mm/2.0 inch |
| Coil material | PISVW |
| Number of layers | 2L(Outside) |
| X-max | 5.6mm |
| Fs | 35 HZ |
| Qts | 0.38 |
| VAS | 107 L |
| Bl | 12.8 Tm |
| Net Weight | 4.5 kg/pc |
