| Nominal diameter | 15"/380mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 800 W |
| Power rating | 1600 W |
| Sensitivity | 97dB |
| Frequency range | 46-1000 Hz |
| Maqnet Size | 220mmX25 |
| Voice coil diametel | 100mm/4 inch |
| Coil material | PISV-W |
| Number of layers | 2L(lnside/Outside) |
| X-max | 11.5mm |
| Fs | 46 HZ |
| Qts | 0.34 |
| VAS | 83 L |
| Bl | 25.8 Tm |
| Net Weight | 11.6 kg/pc |
