| Model | L18QD | CS-112D | CS-304D | CS-304L |
| Frequency response | 40Hztocut(-6dB) | 45Hztocut(-6dB) | 200Hz-20KHz(-6dB) | 200Hz-20KHz(-6dB) |
|
Sensitivity
(1w@1m) |
98dB | 97dB | 93dB | 93dB |
| Rated impedance | 8ohms | 8ohms | 8ohms | 8ohms |
|
Maximum SPL(1m) |
128dB | 126dB | 114dB | 114dB |
| rated power | 600W | 400W | 120W | 120W |
| Amplifier power | 1200W+800W/DSP32bit96K | 800W+800W/DSP 32bit96K | / | / |
|
Coverage Pattern |
/ | / | 120°x15°(HxV) | 120°x15°(HxV) |
| Dimensions (H x W x T) | 600x550x730mm | 608mmx360mmx400mm | 420mmx102mmx114mm | 456mmx102mmx114mm |
| Net Weight | 45kg | 25.5kg | 3kg | 3.4Kg |
| LF speaker | 1x18"100 core 220 magnetic | 1x12" 75 core 190 magnetic | 4x3" 20 core 65 magnetic | 4x3" 20 core 65 magnetic |
| HF speaker | / | / | / | / |
| input connectors | 2xNL4 | 2-coresocket | 2-coresocket | 2-coresocket |
| Enclosure construction | 18mm plywood | 18mm plywood | 10mm plywood | 10mm plywood |
