| Model | CX-12 | CX-15 | H-304 | H-306 |
| Frequency response | 58Hz-18KHz(-6dB) | 55Hz-18KHz(-6dB) | 200Hz-20KHz(-6dB) | 200Hz-20KHz(-6dB) |
|
Sensitivity
(1w@1m) |
96dB | 97dB | 92dB | 93dB |
| Rated impedance | 8ohms | 8ohms | 8ohms | 6ohms |
|
Maximum SPL(1m) |
122dB | 123dB | 113dB | 114dB |
| rated power | 400W | 400W | 120W | 180W |
| crossover point | 1.8KHz | 1.8KHz | / | / |
|
Coverage Pattern |
80°x80°(HxV) | 80°×80(HxV) | 120°x15°(HxV) | 100°x15°(HxV) |
| Dimensions (H x W x T) | 520mmx410mmx420mm | 550mmx440mmx470mm | 420mmx102mmx114mm | 540mmx102mmx114mm |
| Net Weight | 18kg | 23kg | 3kg | 3.5kg |
| LF speaker | 1x12" 75 core 190 magnetic | 1x15" 75 core 190 magnetic | 4x3" 20 core 65 magnetic | 6x3" 20 core 65 magnetic |
| HF speaker | 1x1.0"(44 core) | 1x1.0"(44 core) | / | / |
| input connectors | 2xNL4 | 2xNL4 | 2xNL4 | 2xNL4 |
| Enclosure construction | 15mm plywood | 15mm plywood | 10mm plywood | 10mm plywood |
