| Nominal diameter | 12"/305mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 450 W |
| Power rating | 900 W |
| Sensitivity | 98dB |
| Frequency range | 44-3000 Hz |
| Maqnet Size | 190mm |
| Voice coil diametel | 75mm/3 inch |
| Coil material | PICCAW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 6.5mm |
| Fs | 44 HZ |
| Qts | 0.33 |
| VAS | 79 L |
| Bl | 16.5 Tm |
| Net Weight | 6.8 kg/pc |
