| Nominal diameter | 6.5"/165mm |
| Magnet type | Neodymium |
| Impedance | 8Ω |
| AES Power | 120 W |
| Power rating | 240 W |
| Sensitivity | 97dB |
| Frequency range | 107-5000 Hz |
| Maqnet Size | 250mm*10 |
| Voice coil diametel | 51mm/2 inch |
| Coil material | PIALW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 5.1mm |
| Fs | 107 HZ |
| Qts | 0.32 |
| VAS | 4.8 L |
| Bl | 11.5 Tm |
| Net Weight | 1.75 kg/pc |
