| Nominal diameter | 8"/203mm |
| Magnet type | Neodymium |
| Impedance | 8Ω |
| AES Power | 200 W |
| Power rating | 400 W |
| Sensitivity | 103dB |
| Frequency range | 222-3000 Hz |
| Maqnet Size | 131mm |
| Voice coil diametel | 75mm/3 inch |
| Coil material | PIALW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 4.9mm |
| Fs | 222 HZ |
| Qts | 0.23 |
| VAS | 1.49 L |
| Bl | 27.8 Tm |
| Net Weight | 3.4 kg/pc |
