| Nominal diameter | 8"/200mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 400 W |
| Power rating | 800 W |
| Sensitivity | 92dB |
| Frequency range | 58-1000Hz |
| Maqnet Size | 180mmx20-4 |
| Voice coil diametel | 75mm/3 inch |
| Coil material | PISV-W |
| Number of layers | 2L(lnside/Outside) |
| X-max | 10.5mm |
| Fs | 58HZ |
| Qts | 0.3 |
| VAS | 9L |
| Bl | 18.2Tm |
| Net Weight | 13.6 kg/pc |
