| Nominal diameter | 15"/381mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 400 W |
| Power rating | 800 W |
| Sensitivity | 98dB |
| Frequency range | 35-3000 Hz |
| Maqnet Size | 200mm |
| Voice coil diametel | 75mm/3 inch |
| Coil material | PICCAW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 6.8mm |
| Fs | 35 HZ |
| Qts | 0.28 |
| VAS | 235 L |
| Bl | 18.2 Tm |
| Net Weight | 9.4 kg/pc |
