| Nominal diameter | 18"/460mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 1300 W |
| Power rating | 2600 W |
| Sensitivity | 96dB |
| Frequency range | 33-1300 Hz |
| Maqnet Size | 253mm |
| Voice coil diametel | 115mm/4.5 inch |
| Coil material | PISVW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 13mm |
| Fs | 33 HZ |
| Qts | 0.42 |
| VAS | 173 L |
| Bl | 26 Tm |
| Net Weight | 16.4 kg/pc |
