| Nominal diameter | 8"/200mm |
| Magnet type | Neodymium |
| Impedance | 8Ω |
| AES Power | 200 W |
| Power rating | 400 W |
| Sensitivity | 96dB |
| Frequency range | 69-8000 Hz |
| Maqnet Size | 100mm |
| Voice coil diametel | 51mm/2 inch |
| Coil material | PICCAW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 5.2mm |
| Fs | 69 HZ |
| Qts | 0.35 |
| VAS | 15 L |
| Bl | 12 Tm |
| Net Weight | 2 kg/pc |
