| Nominal diameter | 12"/305mm |
| Magnet type | Neodymium |
| Impedance | 8Ω |
| AES Power | 350 W |
| Power rating | 700 W |
| Sensitivity | 97dB |
| Frequency range | 51-2000 Hz |
| Maqnet Size | 120mm |
| Voice coil diametel | 65mm/2.5 inch |
| Coil material | PISVW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 7.5mm |
| Fs | 51 HZ |
| Qts | 0.23 |
| VAS | 61.8 L |
| Bl | 20.8 Tm |
| Net Weight | 3.5 kg/pc |
