| Nominal diameter | 12"/310mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 500 W |
| Power rating | 1000 W |
| Sensitivity | 97dB |
| Frequency range | 52-3000 Hz |
| Maqnet Size | 190mm |
| Voice coil diametel | 86mm/3.5 inch |
| Coil material | PICCAW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 7.3mm |
| Fs | 52 HZ |
| Qts | 0.34 |
| VAS | 55.5 L |
| Bl | 17.8 Tm |
| Net Weight | 7.5 kg/pc |
