| Nominal diameter | 18"/460mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 1500 W |
| Power rating | 3000 W |
| Sensitivity | 96dB |
| Frequency range | 37-1500 Hz |
| Maqnet Size | 280X25mm |
| Voice coil diametel | 125mm/5 inch |
| Coil material | PISV-W |
| Number of layers | 2L(Inside/Outside) |
| X-max | 12mm |
| Fs | 37 HZ |
| Qts | 0.37 |
| VAS | 140 L |
| Bl | 28.8 Tm |
| Net Weight | 18.5 kg/pc |
