| Nominal diameter | 12"/320mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 1300 W |
| Power rating | 2600 W |
| Sensitivity | 96dB |
| Frequency range | 95-5000 Hz |
| Maqnet Size | 280X25mm |
| Voice coil diametel | 125mm/5 inch |
| Coil material | PICCAW-W |
| Number of layers | 2L(Inside/Outside) |
| X-max | 8mm |
| Fs | 96 HZ |
| Qts | 0.53 |
| VAS | 9 L |
| Bl | 25.8 Tm |
| Net Weight | 17 kg/pc |
