| Nominal diameter | 12"/305mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 600 W |
| Power rating | 1200 W |
| Sensitivity | 97dB |
| Frequency range | 35-1600 Hz |
| Maqnet Size | 220mm |
| Voice coil diametel | 100mm/4 inch |
| Coil material | PISVW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 9mm |
| Fs | 36 HZ |
| Qts | 0.28 |
| VAS | 47.4 L |
| Bl | 23.9 Tm |
| Net Weight | 11.3 kg/pc |
