| Nominal diameter | 15"/381mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 1300 W |
| Power rating | 2600 W |
| Sensitivity | 96dB |
| Frequency range | 45-1500 Hz |
| Maqnet Size | 280mm |
| Voice coil diametel | 125mm/5 inch |
| Coil material | PISVW |
| Number of layers | 2L(lnside/Outside) |
| X-max | 12mm |
| Fs | 45 HZ |
| Qts | 0.52 |
| VAS | 55 L |
| Bl | 25.4 Tm |
| Net Weight | 16.5 kg/pc |
