| Nominal diameter | 8"/200mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 200 W |
| Power rating | 400 W |
| Sensitivity | 95dB |
| Frequency range | 78-4K Hz |
| Maqnet Size | 50mm |
| Voice coil diametel | 50mm/2 inch |
| Coil material | PISVW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 5.6mm |
| Fs | 78 HZ |
| Qts | 0.54 |
| VAS | 12.2 L |
| Bl | 9.9 Tm |
| Net Weight | 4.2 kg/pc |
