| Nominal diameter | 12"/310mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 500 W |
| Power rating | 1000 W |
| Sensitivity | 96dB |
| Frequency range | 36-2000 Hz |
| Maqnet Size | 190mm |
| Voice coil diametel | 86mm/3.5 inch |
| Coil material | PISVW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 8mm |
| Fs | 36 HZ |
| Qts | 0.28 |
| VAS | 80 L |
| Bl | 19.1 Tm |
| Net Weight | 7.4 kg/pc |
