| Nominal diameter | 10"/250mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 250 W |
| Power rating | 500 W |
| Sensitivity | 97dB |
| Frequency range | 53-3000 Hz |
| Maqnet Size | 156mm |
| Voice coil diametel | 65mm/2.5 inch |
| Coil material | PIALW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 6.1mm |
| Fs | 53 HZ |
| Qts | 0.45 |
| VAS | 36.5 L |
| Bl | 11.9 Tm |
| Net Weight | 4.35 kg/pc |
