| Nominal diameter | 18"/460mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 1500 W |
| Power rating | 3000 W |
| Sensitivity | 98dB |
| Frequency range | 29-1000 Hz |
| Maqnet Size | 253mmX30 |
| Voice coil diametel | 115mm/4.5 inch |
| Coil material | PISV-W |
| Number of layers | 2L(lnside/Outside) |
| X-max | 14mm |
| Fs | 29 HZ |
| Qts | 0.27 |
| VAS | 290 L |
| Bl | 27.8 Tm |
| Net Weight | 16 kg/pc |
