| Nominal diameter | 10"/250mm |
| Magnet type | Neodymium |
| Impedance | 16Ω |
| AES Power | 300 W |
| Power rating | 600 W |
| Sensitivity | 97dB |
| Frequency range | 65-3000 Hz |
| Maqnet Size | 74mm |
| Voice coil diametel | 75mm/3 inch |
| Coil material | PICCAW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 10.8mm |
| Fs | 65 HZ |
| Qts | 0.42 |
| VAS | 27.9 L |
| Bl | 19.2 Tm |
| Net Weight | 3.8 kg/pc |
