| Nominal diameter | 12"/305mm |
| Magnet type | Neodymium |
| Impedance | 8Ω |
| AES Power | 400 W |
| Power rating | 800 W |
| Sensitivity | 97dB |
| Frequency range | 49-2000 Hz |
| Maqnet Size | 48mm |
| Voice coil diametel | 51mm/2 inch |
| Coil material | PIAL |
| Number of layers | 1L(Outside)*2 |
| X-max | 7mm |
| Fs | 49 HZ |
| Qts | 0.29 |
| VAS | 73 L |
| Bl | 17 Tm |
| Net Weight | 1.85 kg/pc |
