| Nominal diameter | 18"/457mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 1200 W |
| Power rating | 2400 W |
| Sensitivity | 98dB |
| Frequency range | 38-2000 Hz |
| Maqnet Size | 220mm*2 |
| Voice coil diametel | 100mm/4 inch |
| Coil material | PISVW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 14mm |
| Fs | 38 HZ |
| Qts | 0.38 |
| VAS | 163 L |
| Bl | 28.8 Tm |
| Net Weight | 20 kg/pc |
