| Nominal diameter | 12"/305mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 400 W |
| Power rating | 800 W |
| Sensitivity | 98dB |
| Frequency range | 45-2000 Hz |
| Maqnet Size | 180mm |
| Voice coil diametel | 75mm/3 inch |
| Coil material | PISVW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 6.6mm |
| Fs | 45 HZ |
| Qts | 0.31 |
| VAS | 94 L |
| Bl | 16.7 Tm |
| Net Weight | 6.2 kg/pc |
