| Nominal diameter | 18"/460mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 2500 W |
| Power rating | 5000 W |
| Sensitivity | 97dB |
| Frequency range | 35-1200 Hz |
| Maqnet Size | 280mmX25 |
| Voice coil diametel | 125mm/5 inch |
| Coil material | PISV-W |
| Number of layers | 2L(lnside/Outside) |
| X-max | 12mm |
| Fs | 35 HZ |
| Qts | 0.34 |
| VAS | 180 L |
| Bl | 28.5 Tm |
| Net Weight | 18 kg/pc |
