| Nominal diameter | 18"/460mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 1000 W |
| Power rating | 2000 W |
| Sensitivity | 97dB |
| Frequency range | 37-1500 Hz |
| Maqnet Size | 220mm |
| Voice coil diametel | 100mm/4 inch |
| Coil material | PISV-W |
| Number of layers | 2L(lnside/Outside) |
| X-max | 12mm |
| Fs | 37 HZ |
| Qts | 0.44 |
| VAS | 150 L |
| Bl | 26.8 Tm |
| Net Weight | 12.5 kg/pc |
