| Nominal diameter | 15"/380mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 500 W |
| Power rating | 1000 W |
| Sensitivity | 98dB |
| Frequency range | 42-3000 Hz |
| Maqnet Size | 190mm |
| Voice coil diametel | 75mm/3 inch |
| Coil material | PICCAW |
| Number of layers | 2L(lnside/Outside) |
| X-max | 8.08mm |
| Fs | 41 HZ |
| Qts | 0.46 |
| VAS | 158 L |
| Bl | 15.6 Tm |
| Net Weight | 8.8 kg/pc |
