| Nominal diameter | 15"/381mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 1000 W |
| Power rating | 2000 W |
| Sensitivity | 97dB |
| Frequency range | 44-2000 Hz |
| Maqnet Size | 220mm |
| Voice coil diametel | 100mm/4 inch |
| Coil material | PISVW |
| Number of layers | 2L(lnside/Outside) |
| X-max | 7.3mm |
| Fs | 44 HZ |
| Qts | 0.36 |
| VAS | 87.6 L |
| Bl | 27.1 Tm |
| Net Weight | 18.5 kg/pc |
