| Nominal diameter | 18"/460mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 1500 W |
| Power rating | 3000 W |
| Sensitivity | 96dB |
| Frequency range | 43-1500 Hz |
| Maqnet Size | 280mm |
| Voice coil diametel | 125mm/5 inch |
| Coil material | PISVW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 12mm |
| Fs | 43 HZ |
| Qts | 0.38 |
| VAS | 137 L |
| Bl | 29 Tm |
| Net Weight | 17.5 kg/pc |
