| Nominal diameter | 15"/380mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 1300 W |
| Power rating | 2600 W |
| Sensitivity | 97dB |
| Frequency range | 36-1000 Hz |
| Maqnet Size | 253mm |
| Voice coil diametel | 115mm/4.5 inch |
| Coil material | PISVW |
| Number of layers | 2L(lnside/Outside) |
| X-max | 14mm |
| Fs | 36 HZ |
| Qts | 0.4 |
| VAS | 101 L |
| Bl | 24.3 Tm |
| Net Weight | 14.4 kg/pc |
