| Nominal diameter | 12"/305mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 450 W |
| Power rating | 900 W |
| Sensitivity | 97dB |
| Frequency range | 49-2500 Hz |
| Maqnet Size | 180mm |
| Voice coil diametel | 75mm/3 inch |
| Coil material | PICCAW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 6.8mm |
| Fs | 49 HZ |
| Qts | 0.42 |
| VAS | 70.6 L |
| Bl | 13.9 Tm |
| Net Weight | 7.3 kg/pc |
