| Nominal diameter | 18"/457mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 1000 W |
| Power rating | 2000 W |
| Sensitivity | 96dB |
| Frequency range | 42-1300 Hz |
| Maqnet Size | 220mm |
| Voice coil diametel | 100mm/4 inch |
| Coil material | PISVW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 12mm |
| Fs | 42 HZ |
| Qts | 0.48 |
| VAS | 127 L |
| Bl | 24.2 Tm |
| Net Weight | 10.4 kg/pc |
