| Nominal diameter | 10"/254mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 350 W |
| Power rating | 700 W |
| Sensitivity | 97dB |
| Frequency range | 62-3000 Hz |
| Maqnet Size | 170mm |
| Voice coil diametel | 75mm/3 inch |
| Coil material | PICCAW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 7.08mm |
| Fs | 62 HZ |
| Qts | 0.36 |
| VAS | 29.5 L |
| Bl | 14.5 Tm |
| Net Weight | 5.85 kg/pc |
