| Nominal diameter | 18"/450mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 1000 W |
| Power rating | 2000 W |
| Sensitivity | 98dB |
| Frequency range | 47-1800 Hz |
| Maqnet Size | 220mm |
| Voice coil diametel | 100mm/4 inch |
| Coil material | PISVW |
| Number of layers | 2L(Inside/Outside) |
| X-max | 10mm |
| Fs | 47 HZ |
| Qts | 0.53 |
| VAS | 110 L |
| Bl | 23.9 Tm |
| Net Weight | 12 kg/pc |
